Bend Insensitive Fiber Patch Cords / Jumper Cables

A fiber jumper, sometimes called a fiber patch cord, is a length of fiber cabling fitted with connectors at each end.  They are used to connect end devices or network hardware.

Ask a Question

How Can We Help?

BABA Compliant

BABA Compliant Option Ready for Order

This product meets BABA compliance standards and is available to order. To learn more, please contact one of our sales representatives.

Product Details

Indoor Bend-Insensitive Fiber Jumper Cables are used in a variety of carrier networks and private network environments.  The key to manufacturing high-performance fiber assemblies is controlling polish radius, apex offset and fiber undercut. Clearfield® monitors its automated polishing process to exceed industry specifications for insertion and return loss, ensuring a top-quality product.

Features & Benefits


  • Terminations are designed and tested to Telcordia GR-326
  • Clearfield® FiberDeep® Guarantee: 0.2 dB insertion loss or less, exceeding industry standards
  • Supports industry standard singlemode connectors
  • Singlemode G.657.A1 and A2 bend-insensitive glass fiber


  • Riser and Plenum rated bend-insensitive jacket options available
  • Available in simplex, dual-round and dual zip-cord configurations


  • Compact jacket design minimizes cable pile up
  • Industry standard terminations include SC and LC (ask a Clearfield representative for other connector availability)


  • Indoor Bend-Insensitive Fiber Jumper Cables offer an economical solution for deploying fiber in any optical network
  • Environmentally stable, low-insertion loss, minimal back reflection
  • All assemblies are 100% tested

Technical Specifications

Specification Description
Core Size and Type Singlemode (G.657.A1 and G.657.A2)
Fiber Count Simplex (1-fiber) and Duplex (2-fiber)
Jacket O.D. 2.0 mm
Cable Types Indoor Riser
Connector Types SC/UPC, SC/APC, LC/UPC, LC/APC
Operating Temperature -40°C to 85°C  (-40°F to 185°F)

Minimum Performance Specifications for Terminated Singlemode Connectors

Connector Type Ferrule Material Polish Type Ins. Loss Typical (dB) Max Ins. Loss (dB) Min. Ret. Loss (dB)
SC Ceramic UPC 0.15 0.20 55.00
LC Ceramic UPC 0.15 0.20 55.00
SC Ceramic APC 0.15 0.20 65.00
LC Ceramic APC 0.15 0.20 65.00
